Cadence培訓高級班將首先讓您了解CB板上出現的信號反射、串?dāng)_、電源/地平面干擾、時序匹配以及電磁兼容性等一系列問題產生的機理，并掌握其解決方法；然后講解并上機練習Cadence的高速 PCB設計與仿真工具SPECCTRAQuest的使用。使您在硬件設計過程中，能夠達到“設計即正確”的目的。

        在工作實踐中遇到了高速數字電路與高速PCB設計問題；對高速PCB設計感興趣的硬件工程師；已經具備一定的硬件開發經驗，需要增加就業競爭力的在校碩士及博士研究生；具備非常扎實的電子工程基本知識，并積累了相當程度的硬件工程師工作經驗的在校本科生。

        堅持小班授課，為保證培訓效果，增加互動環節，每期人數限3到5人。注意：本課程一旦開課不予退費。

        1、培訓過程中，如有部分內容理解不透或消化不好，可免費在以后培訓班中重聽；
        2、課程完成后,授課老師留給學員手機和Email,保障培訓效果,免費提供半年的技術支持。
        3、培訓合格學員可享受免費推薦就業機會。

◆【黃老師】

有15年的FPGA和DSP系統硬件開發經驗,8年視頻和圖像處理領域的高速DSP系統硬、軟件和FPGA系統的設計和開發經驗，高速系統設計經驗非常豐富，精通Allegro cadence和candence SPECCTRAQuest等信號完整性仿真，精通高速PCB SI仿真工具以及PADS,Altium Designer等PCB設計工具。

★更多師資力量請見曙海師資團隊。

第一階段

1 高速PCB設計中的理論基礎
    傳輸線理論、信號完整性（反射、串?dāng)_、過沖、地彈、振鈴等）、電磁兼容性和時序匹配等等。
2 SPECCTRAQuest設計流程
    2.1 Pre-Placement
    2.2 Board Setup Requirements for Extracting and Applying Topologies
    2.3 Database Setup Advisor
        —Cross-Section
        —DC Nets
        —DC Voltages
        —Device Setup . ??—SI Models
        —SI Audit

3 拓?fù)浣Y(jié)構的抽取與仿真 Extracting and Simulating Topologies
    3.1 Pre-Route Extraction Setup—Default Model Selection.
    3.2 Pre-Route Extraction Setup—Unrouted Interconnect
    3.3 Pre-Route Template Extraction
    3.4 SQ Signal Explorer Expert
    3.5 Analysis Preferences
    3.6 SigWave
    3.7 Delay Measurements

第二階段

4 確定和施加約束 Determining and Adding ConstraintsSolution
    4.1 Solution SpaceAnalysis: Step 1 to 6
    4.2 Parametric Sweeps.
    4.3 Constraints :
        Topology Template Constraints
        Switch/Settle Constraints
        Assigning the Prop Delay Constraints
        Impedance Constraint
        Relative Propagation Delay Constraint
        Diff Pair Constraints
        Max Parallel Constraint
        Wiring Constraint
        User-Defined Constraint
        Signal Integrity Constraints
    4.4 Usage of Constraints Defined in Topology Template

5 模板應用和基于約束的布局
    Template Applications and Constraint-Driven Placement
    5.1 Creating a Topology
    5.2 Wiring the Topology
    5.3 TLines and Trace Models
    5.4 Coupled Traces
    5.5 RLGC Matrix of Coupled Trace Models
    5.6 Crosstalk Simulation in SQ Signal Explorer Expert
    5.7 Simulating with Coupled-Trace Models
    5.8 Sweep Simulation Results with Coupled-Trace Models
    5.9 Extracting a Topology Using the Constraint Manager
    5.10 Electrical Constraint Set
    5.11 Applying Electrical CSet
    5.12 Worksheet Analysis
    5.13 Spacing and Physical Rule Sets
    5.14 Electrical Rule Set

第三階段

6 基于約束的布線 Constraint-Driven Routing
    6.1 Manual Routing
    6.2 Routing with the SPECCTRA Smart Route
    6.3 Driving Constraints in Routing
7 布線后的DRC檢查和分析 Post-Route DRC and Analysis
    7.1 Post-Route Analysis
    7.2 SigNoise
    7.3 Reflection Simulation
    7.4 Reflection Waveform Analysis
    7.5 Comprehensive Simulation
    7.6 Crosstalk Simulation
    7.7 Crosstalk Analysis
    7.8 Simultaneous Switching Noise Simulation
    7.9 SSN Waveform Analysis
    7.10 System-Level Analysis
    7.11 A Complete Design Link
    7.12 Initialize Design Link

8 差分信號設計 Differential Pair Design Exploration
    8.1 Types of Differential Pairs in SPECCTRAQuest
    8.2 Create Differential Pair Using SPECCTRAQuest
    8.3 Create Differential Pair Using Constraint Manager
    8.4 Assigning Differential Pair Signal Models
    8.5 Preference to Extract Unrouted Differential Pair Topology
    8.6 Extracting Unrouted Differential Pair Topology
    8.7 Custom Stimulus to Analyze Differential Pair Topology
    8.8 Differential Pair Topology Analysis
    8.9 Coupled Trace Model and Differential Pair Topology
    8.10 Layout Cross-section Editor
    8.11 Differential Pair Constraints
    8.12 Differential Pair Constraints in the Constraint Manager
    8.13 Differential Pair Analysis in the Constraint Manager
    8.14 Post Route Extraction

9 時序仿真和和PI仿真
9.1 時序仿真
9.2 PI仿真

10. 多板仿真和Design Link模型
10.1 Design Link模型的創建和修改
10.2 主板和子板，底板和核心板的接口信息的查找和顯示
10.3 多板仿真建模
10.4 多板仿真主板和子板資源添加和接口連接
10.5 網絡列表創建
10.6 仿真參數設置
10.7 探測仿真

11. SI仿真環境的建立和時序仿真－－DDR3和Flash,高速數據線的時序控制
11.1 SI仿真模型的查找技巧和IBIS格式轉換
11.2 仿真環境的設置和仿真模型分配和審核
11.3 DDR3和Flash,高速數據線時序仿真在項目開發中作用和意義
11.4 時序控制的公式推導和理論基礎
11.5 對應 Setup Time和 Hold Time 公式的深入理解
11.6 公式參數在芯片datasheet中的查找
11.7 時序仿真的高速數據線等網絡組的創建和拓?fù)涮崛?br> 11.8 時序仿真的激勵
11.9 時序仿真類型
11.10 時序仿真結果查看
11.11 時序仿真的約束
11.12 SigXplore和Constraint Manager
11.13 設計規則應用和規則驅動布局
